Products Home > >Control panel box

IP65 NEMA Stainless Steel Enclosures And Boxes

Product Details



Features:

* Material: stainless steel 304,316,201

* Thickness: 1.2mm,1.5mm,2.00mm

* Dimension:300mm x 300mm x 150mm

* Door: single door

* Spare parts: back mounting plate, two locks, hinge

* Surface treatment: Polishing, brushing

* Installation: indoor floor

* Function: electric control enclosure, NEMA type, RITTAL type

* Certificate: CE,IP65

*Working environment: air port, building, hotel, shopping centre, housing estate, school,

Factory, port, highway.



Specifications:

Part Number

Enclosure Dimensions

Mounting plate dimensions

0016-ECPB-TCH

200 ×300 ×150

150 × 250

0017-ECPB-TCH

300 ×300 ×150

250 × 250

0018-ECPB-TCH

300 ×400 ×150

250 × 350

0008-ECPB-TCH

300 ×400 ×200

250 × 350

0009-ECPB-TCH

400 ×400 ×200

350 × 350

0010-ECPB-TCH

400 ×500 ×200

350 × 450

0011-ECPB-TCH

400 ×600 ×200

350 × 550

0012-ECPB-TCH

600 ×600 ×200

550 × 550

0013-ECPB-TCH

600 ×800 ×200

550 × 750

0014-ECPB-TCH

500 ×700 ×250

450 × 650

0015-ECPB-TCH

600 ×600 ×300

550 × 550
